The Crimson
THE CRIMSON
Just when you think "It doesn't get any better"...
The CRIMSON is a top performance custom handbuilt moving coil phono cartridge. A crossbreed of our The CANARY and The CONDOR. THis cartridge is availabale in natural light and darkwood colour as well as in a red coloured (also wooden) version. On special request a Polycarbonate body is available.
Specific characteristics for this great cartridge are a relatively high (0,65mV) output, gold coils, a Samarium-Cobalt magnet, extended channel seperation and superb tracking abillity.
As the popularity of vinyl is reviving again, many requests came in to develop a High-End phono cartridge for a more affordable price than The COLIBRI. The CRIMSON is the result and probably one of the cartridges with the best value for money available. It is completely hand build by the Master himself and comes with a 200 hour service check-up, free of charge (for the original owner).
Special Edition CRIMSON XGA now available with Titanium & Amber Body & Gold Coils.
Production time:
The production time for a CRIMSON cartridge after ordering is about three weeks.
THE CRIMSON |
|
---|---|
version | XGW: wooden body / XGP: polycarbonate body |
stylus replacement | stylus replacement and services available on request |
stylus shape | VDH 1S |
stylus radii | 2 x 85 Micron |
frequency range | 5 - 55.000 Hz |
tracking force | 1,4 - 1,6 Gr |
static compliance | 35 Micron/mN |
tracking ability | 70 - 80 Micron |
output voltage |
0,65mV |
channel unbalance | < 0.3 dB |
channel separation |
> 36 / > 30 dB |
stylus tip mass | 0.32 Milligram |
system weight | 8,75 Gr |
load capacitance | Non critical |
load impedance |
25 Ohm - 200 Ohm |
eff tone arm mass | 10 - 16 Gr |
moving coil resistance |
13,0 Ohm |
Beknopte specificaties
Type product | MC element |
