IN200 Signature

• Symmetrical Output stages with discrete components
• Double pair of MOS-FET transistors on each channel
• Specific low consumption supplies (5VA) for analog circuits and display.
• Capacitors: 8x6800uF low ESR high quality designed specifically for ATOLL.
• 2 volume attenuators: 1 per channel
• Analog stages with Mundorf MKP condensators in a armored shell
• Complete settings (from the front panel or with the remote control) of the balance and volume
• Direct access to each inputs from the front panel or with the remote control

Connectings:

• 5 audio stereo Inputs (RCA):
• CD
• TUNER
• TAPE (IN+OUT)
• AUX ( or optionnal board)
• DVD
• 1 trigger 12V Output
• 1 By-pass Input (uses as power amplifier)
• Double pair of Pre-out by bi-amp.
• Headphones jack

OPTIONAL DIGITAL BOARD:

An optional board with several Digital Inputs is available, including:

• 1 Bluetooth receiver: Direct digital to the AKM audio converter
• 2 Coaxial Inputs (24Bits/192kHz)
• 2 Optical Inputs (24Bits/192kHz)
• 1 USB-B Input: PCM & DSD
  Audio converter: AKM – AK4490
  PCM from 16 bits to 32bits up to 384 kHz on USB-B input (asynchronous).
  DSD : DSD64 & DSD128.
  USB Interface: XMOS with specific program designed for ATOLL.
